Big Feeding Opening Mining Rock Crusher Mining Crushing Equipment Iso9001
Product Introduction
The new impact crusher integrates the current domestic and international new technology to refine the rotor and crushing cavity for different fields of application. We use new high wear-resistant materials to improve equipment performance and capacity greatly. It is a very important mining crushing equipment. The size of the discharge size can be adjusted, and the crushing specifications are diversified.
Features
1. It has a big feeding opening, high crushing chamber, high adaptability of the material hardness and a small number of stone powders.
2. The gap between the impacting plate and the plate hammer is convenient to adjust so that it can effectively control the discharging granularity and the particle shape is good.
3. It has a compact structure and strong rigidness, and the rotor has big rotational inertia.
4. It adopts high chromium plate so that it has shock resistance, abrasion resistance, and big impacting force.
5. It adopts no key links so that it is convenient for maintenance and repair, and it is economical and reliable.
Our Service
After nearly 20 years of industry experience, Fangda Industrial has absorbed the latest technology and concepts at home and abroad to develop products with an international advanced level. The Fangda Industrial has formed its own unique and rich corporate culture.
Impact crusher is one of our hot products, which has exported to more than 100 countries and regions around the world. At the same time, we meet the customer's needs for the ultimate goal and promise 100% ex-factory price to save costs for our customers. We have more products and industry information waiting for you to know! Welcome to consult us online at any time. You can also send an email to our professional salesperson 15333827088@163.com.
Technical Parameter
| Model | Specifications
(mm) | Max feeding size
(mm) | Capacity
(t/h) | Power
(kw) | Total weight
(t) | Dimensions
(LxWxH)
(mm) |
| PF-0607 | 644x740 | 100 | 10-20 | 30 | 4 | 1500x1450x1500 |
| PF-0807 | 850x700 | 300 | 15-30 | 30-45 | 8.13 | 1900x1850x1500 |
| PF-1007 | 1000x700 | 300 | 30-70 | 45 | 12 | 2330x1660x2300 |
| PF-1010 | 1000x1050 | 350 | 50-90 | 55 | 15 | 2370x1700x2390 |
| PF-1210 | 1250x1050 | 350 | 70-130 | 110 | 17.7 | 2680x2160x2800 |
| PF-1214 | 1250x1400 | 350 | 100-180 | 132 | 22.4 | 2650x2460x2800 |
| PF-1315 | 1320x1500 | 500 | 130-250 | 220 | 27 | 3180x2720x2920 |
| PF-1320 | 1320x2000 | 500 | 160-350 | 300 | 30 | 3200x3790x3100 |
